How can I tell the quality of a used Shadick ALN400Qs Jogging Wire?
To judge the quality of used Shadick ALN400Qs jogging wire, you can start from the following aspects:
1. Appearance check
- **Machine tool as a whole**: check the surface of the machine tool for obvious knocks, scratches, paint loss and other damage, if there is more damage, it may mean that the machine tool has been subjected to improper operation or maintenance.
- **Working table**: check the working table surface for wear and deformation, the higher precision requirements of the working table surface if there is a problem, it will affect the machining accuracy.
- **Wire wheel and electrode wire**: check the wire wheel wear, wear and tear will affect the electrode wire walking precision; at the same time to observe the electrode wire tension is uniform, there is no broken wire, messy wire phenomenon.
2. Electrical system check
- **Control cabinet**: open the control cabinet, check whether the internal lines are neat, there is no aging, broken, the electrical components have no traces of overheating, burnt, electronic components pins are not loose.
- **Operating panel**: test the operating panel of the keys, knobs are sensitive, the display is clear, there are no abnormal characters or color blocks.
- **System software**: check the machine tool system software version, to confirm whether the latest or newer version, the version is too low there may be functional limitations or loopholes; at the same time, check whether the software is running stably, there is no lag, crash and other phenomena.
3. Mechanical system check
- **Movement of each axis**: Manually operate the movement of each axis (X, Y, Z, U, V) to check whether the operation is smooth and steady, and whether there is any stuttering, shaking or abnormal noise. Observe whether the positioning accuracy of each axis is accurate by micro-feeding through the handwheel.
- **Screws and guide rails**: Check the wear and tear of the screws and guide rails by observing the glossiness of the surface, the presence of scratches, and measuring their accuracy. If the silk rod and guide rail are seriously worn, it will affect the movement accuracy and stability of the machine tool.
- **Transmission devices**: Check the wear of belts, gears and other transmission devices, whether the belt is loose, cracked, whether the teeth of the gears are worn, missing teeth and other issues.
4. Processing performance test
- **Trial cut workpiece**: Let the machine tool cut some simple workpieces, such as square, round, etc., and then measure the dimensional accuracy of the workpiece, surface roughness and other indicators, and compare them with the nominal accuracy of the machine tool to determine whether the machining accuracy of the machine tool meets the requirements.
- **Observation of the discharge state**: During the test cutting process, observe the stability of the discharge, whether the discharge sound is uniform and crisp, and whether the discharge spark is stable and uniformly blue. If the discharge is not stable, it will affect the processing quality and efficiency.
- **Check taper machining**: Conduct a taper machining test to check the machining accuracy and surface quality of the machine tool under different taper angles, and assess the taper machining capability of the machine tool.
5. Equipment history and maintenance records
- **Useful life and start-up time**: Ask about the useful life and actual start-up time of the equipment. Generally speaking, equipment with a short useful life and less start-up time has relatively less wear and tear on its components and its quality is more guaranteed.
- **Maintenance records**: Check the maintenance records of the equipment, to understand whether the equipment is regularly maintained, maintenance is in place. Such as regular replacement of lubricants, cleaning filters, calibration accuracy and other maintenance work is essential to maintain the performance of the machine tool.
- ** breakdown maintenance records **: to the seller to understand the equipment failure repair situation, including the type of failure has occurred, the number of repairs and the effect of the use of the repairs. If the equipment has frequent major breakdowns, there may be underlying quality issues.
