OKUMA MU-4000V 5 axis machining centre

Three-Axis Travel: 740 × 460 × 460 mm
B-Axis Travel: +90° to -120° (Rotation Range: 210°)
C-Axis Travel: 360° (Infinite Rotation)
Maximum Workpiece Size: Ø500 × H400 mm
Distance from Worktable Surface to Spindle Nose: 120–580 mm
Worktable Size: Ø400 m
Maximum Load: 300 kg
Rapid Movement:
X/Y/Z Axes: 50 m/min
B-Axis: 50 min⁻¹ (Standard)
C-Axis: 120 min⁻¹ (Standard)
Axis Precision:
B-Axis Indexing Precision: ±1.78″
B-Axis Repeatability Precision: ±0.50″
C-Axis Indexing Precision: ±2.26″
C-Axis Repeatability Precision: ±0.12″
