What makes and models of WEDM are recommended?

The following are some recommended brands and models of WEDM :

I. Fanuc

α-C400iB: table travel 400mm × 300mm, Z-axis travel 255mm, can be processed workpiece size 730mm × 630mm × 250mm, the use of wire diameter 0.1-0.3mm, suitable for processing small and medium-sized precision parts, equipment, high precision, automatic threading powerful, can be completed within 10 seconds 0.10 fine line of automatic threading, processing stability, good. It can effectively guarantee the machining precision and surface quality.

α-C600iB: Stroke 600mm×400mm, Z-axis stroke 310mm, workpiece size 1050mm×820mm×300mm, load capacity up to 1000kg, suitable for medium-sized molds and parts machining, high cutting efficiency to meet the needs of mass production, and its high-precision positioning and repetitive positioning system to ensure the consistency of the machining dimensions.

α-C800iB: Table travel 800mm×600mm, Z-axis travel 310mm, workpiece size up to 1250mm×1020mm×300mm, mainly used for large-sized molds and large-sized parts machining, with strong cutting capacity and stability, can adapt to complex shapes and high-precision requirements of the machining task.

II. West

M35HP: the movement of each axis is 350mm×300mm×230mm, the maximum workpiece size is 700mm×630mm×220mm, the maximum workpiece weight is 350kg, the diameter of the wire electrode is 0.07-0.3mm, it is suitable for small precision parts machining, it has the characteristics of high precision and high efficiency, its pitch machining accuracy can reach ±1um, it can meet the high precision requirements for the machining of Its pitch machining accuracy can reach ±1um, which can satisfy the production of parts with extremely high requirements for machining accuracy.

M50B: table stroke 500mm×350mm, maximum cutting thickness 300mm, surface roughness 0.2um, electrode wire diameter range 0.1-0.3mm, maximum load capacity 800Kg, taper ±10°/plate thickness 300mm, can process larger size and weight of the parts, while maintaining high machining accuracy and surface quality, and can adapt to the diversified precision machining Demand.

Shadick

AQ325L: with high cutting accuracy and surface quality, suitable for processing small and medium-sized precision molds and parts, good equipment stability, stable operation for a long time, effectively reduce production interruptions due to equipment failure, improve production efficiency.

AQ400LS: With excellent processing accuracy and stability, it can realize high-precision cutting processing and is suitable for processing parts with strict requirements on dimensional accuracy and surface roughness, such as precision molds and aerospace parts.

ALN400: balanced performance in cutting efficiency and accuracy, can meet the general demand for precision parts processing, has a good cost-effective, suitable for small and medium-sized enterprises and processing workshop selection.

Sharmilles

CUT P 350 Pro: wire guide nozzle diameter standard configuration for 0.10-0.30mm, the maximum cutting taper 30 ° / 100mm, X, Y axis of the highest moving speed of 3m/min, can penetrate the wire height of 250mm, suitable for processing small precision parts, with high precision, high efficiency, and its advanced electronic control system can provide higher processing accuracy and stability.

CUT P 550 Pro: similar performance to CUT P 350 Pro, but the processing size range is larger, can meet the processing needs of medium-sized parts, with higher cutting accuracy and surface quality, can effectively improve processing efficiency and product quality.

CUT P 800 Pro: can process larger size parts, the maximum cutting taper and can be threaded height and other parameters are further improved, suitable for large molds and parts processing, its stable cutting performance and high-precision machining capabilities to ensure that large parts of the processing accuracy and quality.

Five, Mitsubishi

FA20S: suitable for processing small precision parts, with high processing accuracy and stability, high success rate of automatic threading, easy to operate, can effectively improve processing efficiency, reduce labor costs, suitable for small and medium-sized enterprises and processing workshop use.

MV1200S: Adopting sleeve linear motor drive and Opt Drive System, it improves machining precision and response speed, realizes high-speed machining of micro-fine surfaces, greatly improves the success rate of automatic threading of electrode wires, and extends the corresponding range of bending rate from 3% to 10%, and greatly improves the success rate of threading of broken wires of thick plates, and it is suitable for the parts with high requirements for machining precision and surface quality. Processing.

DWC-200HA: excellent performance in terms of precision and efficiency, can meet the needs of medium and large molds and parts processing, its advanced drive system and control system to ensure the stability and accuracy of the processing process, improve productivity.

VI. Precision Presentation

V50 water jet type: large workpiece size 950mm × 650mm × 255mm, XY axis travel 500mm × 300mm, UV axis travel 120mm × 120mm, Z-axis travel 260mm, the use of wire diameter 0.15-0.3mm, the use of a stable arc voltage circuit and electrolysis-free discharge power supply system, which can maintain the stability of the cutting and improve the speed, and at the same time, to extend the life of the mold. The RTS discharge circuit can effectively monitor the discharge state, reduce the phenomenon of wire breakage, and improve the processing efficiency and precision.
