Specifications:
Worktable size: 600*300mm
Maximum worktable travel: left-right: 600mm, front and rear: 330mm
Maximum distance from worktable surface to spindle center: 540mm
Maximum worktable load(including magnetic worktable) : 420kg
Worktable speed: 5-25m/min
Front and rear remote control box feed rate (1 grid /1 circle) : 0.02/4mm
Front and rear automatic feed: 0.0-10mm
Front and rear fast feed rate(50HZ/60HZ) : 790/950mm/min
Upward and downward remote control box feed rate(1 grid/1 circle) : 0.001/0.5mm
Upward and downward automatic feed rate: 0.005-0.025mm
Upward and downward fast feed rate: 230mm/min
Grinding wheel size (external diameter*hickness.*internal diameter) : 355*20~40*127mm
Spindle speed (50HZ/60HZ) : 1450/1740rpm
Spindle motor: 5HP
Front and rear motors: 40W
Upper and lower motor: 80W
Motor for oil presuring : 2HP
Motor for flushing: 1/4HP
Machine footage: 3500*2500*1830mm
Machine weight(net weight/ gross weight)：1750/1950kg
