MAXMILL   VMC-1690
Vertical Machining centre
[Product Information:]
  • Inventory number：90320
  • Brand：MAXMILL
  • Model：VMC-1690
  • Origin：Taiwan
  • Location：China
  • Year：2010
  • Create Time：2023-08-19

Specifications:

  • Three axes travel: 1600x900x700mm

    Distance from spindle nose to worktable: 200-900mm

    Distance from spindle center to column: 990mm

    Worktable size: 1900x850mm

    Worktable load: 2000kg

    T-slot: 5x22x150mm

    Spindle speed: 6000rpm

    Main motor power: 15kw

    Machine weight: 12800kg

    Machine footage: 4030x3530x3280mm

    CNC System: Mitsubishi M70

    BT50

    Three axes rigid guideway
