• Inventory number：10701
• Brand：STUDER
• Model：S 40 CNC
• Origin：Switzerland
• Location：China
• Year：1998
• Create Time：2023-08-01

Specifications:

• distance between centers : 1000 mm

  centers height : 175 mm

  strokes (Z/X) : 1050 x 275 mm

  max. feeds (Z/X) : 10 x 5 m/min

  grinding wheelhead type : 2 external, 1 internal

  left external grinding wheel dimension : 500 x 63 x 127 mm

  right grinding wheel dimension : 400 x 63 x 127 mm

  grinding wheel motor power : 7,5 kW

  rotation speed : 1670 - 2110 Rpm

  grinding wheelhead orientation : -15 to +225 °

  resolution : 0.001 °

  workhead rotation speed : 1 - 1027 Rpm

  workhead power : 0,785 kW

  tail stock : MT3- quill stroke : 35 mm

  weight : 7000 kg

  hours under power : 37.704 h
