• Inventory number：70740
• Brand：Alex-tech
• Model：VT-8
• Origin：Taiwan
• Location：China
• Year：2010
• Create Time：2023-05-26

Specifications:

• Maximum rotation diameter (Z-axis telescopic guard)   320mm

  Maximum machining diameter 120mm

  Maximum rotating diameter (slide) 120mm

  Maximum machining length 90mm

  X-axis travel 210mm

  Z-axis travel 180mm

  Spindle nose type ISO A2-4

  Collet external diameter 125mm

  Spindle front bearing 65mm

  Spindle through hole 35mm

  Bar diameter 26mm

  Spindle motor 3.75KW

  Spindle speed 6000rpm

  Square tool holder height 12mm

  Maximum boring tool 20mm

  X-axis feed rate 15m/min

  Z-axis feed rate 15m/min

  Floor area 1530*1310mm

  Machine weight  1850kg
