• Inventory number：70247
• Brand：AgieCharmilles
• Model：CUT 200BP
• Origin：Switzerland
• Location：China
• Year：2016
• Create Time：2023-05-19

Specifications:

• Brand: AgieCharmilles Slow Wire Cutting

  Model: CUT200BP

  X-axis travel: 350mm

  Y-axis travel: 220m

  Z-axis travel: 220mm

  U-axis travel: 350mm

  V-axis travel: 220mm

  Maximum workpiece size: 1000x550x220mm

  Machining taper: 5-80mm

  Electrode wire diameter: 0.15-0.03mm

  Maximum workpiece weight :750KG

  Minimum machining accuracy:0.1um

  Water tank volume: 1200L

  Standard electrical/power: 3 hz11kva x380v / 400 v ⱱ 0% 50/60

  Weight: 3500KG

  Machine tool footage: 2030x2201x2000mm
