• Inventory number：20099
• Brand：Scandinavia
• Model：SNC-20B
• Origin：China
• Location：China
• Year：2016
• Create Time：2023-05-04

Specifications:

• Maximum turning diameter 240mm

  Rotary diameter over slide plate 120mm

  Maximum machining diameter  100mm

  Maximum machining length  100mm

  Spindle speed 7000rpm

  Spindle through hole diameter 20mm

  Spring collet holder diameter 26mm

  X axis fast feed rate 40m/min

  Z axis fast feed rate 40m/min

  X axis travel  230mm

  Z axis travel  160mm

  Spindle motor 2.2/3.7kw

  Feed motor 0.75kw * 0.75kw

  Spindle center height 970mm

  Machine weight 1600kg
