Specifications:
X-axis travel 900mm
Y-axis travel 650mm
Z-axis travel 600mm
Worktable size (X x Y) 1100x650mm
Distance from spindle nose to worktable surface 125-725mm
Maximum worktable load 900kg
Height from worktable to ground 900mm
Belt type spindle speed 8000rpm
Spindle power (continuous /30 min) 7.5/11kw
Spindle taper BT-40
Spindle torque (continuous /30 minutes) 48/70Nm
Fast feed rate(X/Y/Z) 24/24/20mm/min
Cutting feed rate 10mm/min
