• Inventory number：80277
• Brand：Toshiba
• Model：MPF-5 (C)
• Origin：Japan
• Location：China
• Year：
• Create Time：2023-01-09

Specifications:

• Brand and model : Toshiba MPF-5（C）

  Effective door width: 1600mm

  Travels:

  X-axis: 1000mm

  Y-axis: 1600mm

  Z-axis: 600mm

  Axis A: ± 30 degrees

  C-axis: ± 360 degrees

  Door height: the maximum distance from the table top to the spindle end is 900mm

  Worktable size: 1300 * 1000mm

  Maximum load of worktable: 4000kg

  Spindle rotation speed: 120~12000 rpm

  Maximum torque of main shaft: 205/300N. m

  Feed speed:

  X、Y：20000mm/min

  Z：10000mm/min

  A：1000mm/min

  C：1000mm/min

  Cutting speed:

  X、Y、Z：1-10000mm/min

  A：1-1000mm/min

  C：1-720mm/min

  Spindle motor: AC 37/30KW,

  Machine floor area: 4420*4720*4320 ,

  Weight: about 29 tons
