Table size 2,000*800 mm Maximum load: 10,000 kgf Spindle drive mode - GEAR(3STEP) Spindle taper - BT50 Maximum spindle speed 2,000 r/min spindle power 22/18.5 kW Maximum torque of spindle 3,112/2,617 N.m Maximum transfer distance (X/Y/Z) 3,000/2,000/1,600 mm maximum transfer distance (A/C) 700(W-axis) deg fast moving speed (X/Y/Z) 8/8/8 m/min fast moving speed (A/C) 8(W-axis) r/min guide form - BOX Knife library number EA 40 Tool change rhythm (Chip To Chip) 70 sec
