ZhuoYu GF25 other

Core machining capacity
Bending capacity of round steel: Φ4-25mm
Bending capacity of threaded steel: Φ4-22mm
Bending capacity of square steel/flat steel: Compatible with square steel and flat steel
Power and drive CNC System
Motor power: 3 KW
Motor speed: 1440 r/min
Working speed: 25-30 times per point
Drive mode: gear drive
Working voltage: Three-phase 380V
Control and Operation
Bending speed: approximately 500 to 600 stirrups per hour
Angle adjustment range: 0-180° (CNC model 0-360°)
Preset angles: 90° / 135°
Operation mode: Manual control/foot pedal, automatic return
Control mode: CNC panel/travel switch
Physical specifications of the equipment
Overall weight: approximately 135-210 kg
Overall dimensions: approximately 850 × 570 × 900 mm
