manhaTnc MHT-65T/2550 Bending machine

Nominal Pressure: 650 kN
WorkTable Length: 2550 mm
Distance Between Columns: 2000 mm
Throat Depth: 300 mm
Slider Stroke: 120 mm
Maximum Opening Height Between Table Surface and Slider: 375 mm
Slider Speed:
No-load Speed: 60 mm/s (Adjustable)
Working Speed: 12 mm/s
Return Speed: 75 mm/s
Main Motor:
Model: Y132S-4 B35
Speed: 1440 r/min
Power: 5.5 kW
Hydraulic System:
Pump Model: 10MCY14-1B
Pressure: 31.5 MPa
Flow Rate: 18 ml/r
Maximum Working Pressure of Hydraulic System: 25 MPa
Overall Dimensions (L × W × H): 2500 × 1250 × 1890 mm
