WAIDA AP460 Tool grinder

Grinding Wheel Specifications
Model: ASD270-1/25D30
Overall Dimensions: Diameter 350mm × Total thickness 90mm × Installation hole diameter
Grinding Wheel Size: Diameter 260mm (shared with AP-40)
Rotational Speed: 300 to 3000 min⁻¹
Control Axes
X-axis: Grinding wheel engagement
Y-axis: Grinding wheel left-right movement
B-axis: Workpiece axis rotation
C-axis: Variable angle worktable
Drive Motor: 5.5kW three-phase asynchronous motor
Grinding Wheel Forward and Backward Movement (X-axis)
Maximum Travel: 100mm
Maximum Rapid Feed Rate: 10m/min
Minimum Setting Unit: 0.0001mm
Minimum Movement Unit: 0.0001mm
Minimum Detection Unit: 0.0001mm
Drive Motor: 0.85kW AC servomotor
Grinding Wheel Left-Right Movement and Swing (Y-axis)
Maximum Travel: 100mm
Maximum Rapid Feed Rate: 10m/min
Minimum Setting Unit: 0.0001mm
Minimum Movement Unit: 0.001mm
Minimum Detection Unit: 0.001mm
Worktable Fixture - Chuck: General hydraulic cylinder, external type
Travel: 16mm
Dressing Grinding Wheel Size: External diameter 125mm × Hole diameter 42.5mm × Thickness 20mm (Straight type, 2 pieces installed simultaneously)
Dressing Grinding Wheel Speed: 300 to 1500 RPM
Drive Motor: 0.85kW AC servomotor
Workpiece Axis Rotation (B-axis)
Maximum Rapid Feed Rate: 43,200°/min (720°/sec)
Minimum Setting Unit: 0.0001°
Minimum Movement Unit: 0.001°
Minimum Detection Unit: 0.001°
Drive Motor: 0.1kW DC brushless servomotor
Workpiece Swinging and Rotation (C-axis)
Maximum Travel: -30° to +36°
