Specifications:
Maximum machining diameter :660mm
Maximum machining length :1500 mm
X axis travel :750mm
Y-axis travel :±210mm
Z-axis travel :1550+100 mm(with ATC)
B axis rotation Angle :±120°
Spindle speed :4000 rpm(spindle)
Spindle speed 12000 rpm(Tool Spindle speed)
spindle power :22/18.5kW(spindle)
spindle power :18.5/11 kW(spindle spindle)
magazine capacity :100
Tool holder form :Capto C6
tailstock quill shaft MT5 live center
