Specifications:
Distance between centers: 600 mm
Center height: 175 mm
travel X*Z: 320 x 750 mm
Resolution X * Z: 0.0001mm
grinding wheel retainer headstock automatic rotation direction: -210/+10° grinding wheel degree cell
Maximum workpiece weight (between centers) : 100KG
Left external grinding: grinding wheel Footage (diameter X width X boring) 400 x 63 x 127mm
Right external grinding: grinding wheel size (diameter X width X boring) : 300x 40 x 127mm
Internal grinding * speed: 6000-28000rpm
Power supply voltage: 400 volts
Machine Footage: 2400 x 1700 x 1800 mm
Machine weight: 3500 kg
