Specifications:
Length of Worktable: 600mm
WorkWorktable width: 380mm
X axis travel: 500mm
Y-axis travel: 300mm
W axis travel: 450mm
WorkWorktable load: 250kg
Grinding diameter: 230mm
Display disk: 360mm
travel of spindle head: 340mm
Grinding taper angle: 16.0 °
Grinding shaft vertical travel (non-polar) : 1-110mm
travel speed (non-polar) : 0-9 m/min
Z-axis: 0.5-12000mm/min
travel frequency: Z4 Hz
travel length Z (unlimited adjusWorktable) : 110mm
U-axis: 5.5mm
C-axis (non-polar) : 5-300rpm
Possible grinding spindle speed (non-polar) : 4500-80000rpm
Air turbine: 160000rpm
Working voltage: 50Hz3x380Volt
machine tool weight: 4100kg
Footage (length * width * height) : 2650*1700*2850mm
