• Inventory number：92408
• Brand：DMG
• Model：CTX 5106eCo
• Origin：Germany
• Location：China
• Year：2011
• Create Time：2024-11-12

Specifications:

• machining  length :1150mm

  Rotation diameter :465mm

  Bed rotation range :680mm

  X slide plate drive range :465mm

  XZ B axisall screw rod drive D*P:40*10mm

  XZ feed force :7.5kn

  XZC1 axis Fast moving rate :30/30/100m/min

  chuck  diameter :250mm

  Spindle through hole diameter :103mm

  spindle power :22/33kw

  Bar through hole :76mm

  turning diameter :465mm

  XZ axis travel :300*1050mm

  Equipped with hydraulic center rest
