• Inventory number：84837
• Brand：Okamoto
• Model：OGM250EXIII
• Origin：Japan
• Location：China
• Year：2018
• Create Time：2024-09-19

Specifications:

• Intermediate distance: 500mm

  Maximum machining  diameter: 200mm

  X, Z maximum travel: 215*762mm

  grinding wheel size: 355*38*127mm

  speed: 1614 ~ 2247min-1

  Maximum weekly speed: 30m/sec

  Worktable rotation Angle: 0° ~ -9°

  spindle and tailstock through hole: MT3

  spindle Worktable hole diameter: 18mm

  speed: 10 ~ 500min-1

  Rotation Angle: 30° ~ -90°

  tailstock travel: 20mm

  Mechanical size: 2920*2010*1950mm

  Machine weight: 3400KG
