• Inventory number：84632
• Brand：KAFO
• Model：vmc-1688
• Origin：Taiwan of China
• Location：China
• Year：2018
• Create Time：2024-08-31

Specifications:

• three-axis travel :1600*880*700mm

  Distance from nose of spindle to WorkWorktable :200-900mm

  Distance from Distance from spindle center to column track plane :935mm

  WorkWorktable size :1800*950mm

  WorkWorktable load :2500kg

  Spindle speed :BT50

  Spindle speed :6000rpm

  spindle motor :15/18.5kw

  3 axes fast :20/20/15m/min

  Footage: 5317*4050*3112mm

  Weight :17000kg

  3 axes rigid guideway heavy duty gear case 3 axes

  It is equipped with high pressure spindle Center flushing Tool arm type Tool magazine
