• Inventory number：61595
• Brand：Okamoto
• Model：ACC52DX
• Origin：日本
• Location：China
• Year：2007
• Create Time：2024-08-24

Specifications:

• Worktable size: 550*200mm
  Chuck size: 500*200*80mm
  Working load capacity (including chuck ) : 200KG
  T-slot (width X number of slots) : 17X1mm
  Left and right feed speed: 0.3~25(m/min)
  Rotation of the left and right handles for 1 cycle feed: 47(mm)
  Intermittent feed: 0.2-12(mm)
  Continuous feed speed: 0.1-1.0(m/min)
  Non-spark grinding: 0-5 times
  Up-down feed speed: 600mm/min
  Maximum vertical feed: 650(mm)
  Lateral feed: 230(mm)
  grinding wheel transfer (50/60HZ) : 3000/3600rpm
