Makino   F68-5Xi
5 axis machining centre
[Product Information:]
  • Inventory number：84564
  • Brand：Makino
  • Model：F68-5Xi
  • Origin：Japan
  • Location：China
  • Year：2011
  • Create Time：2024-08-23

Specifications:

  • three-axis travel: 400*300*200mm

    Worktable size: 230mm

    Maximum load: 20kg

    Positioning Accuracy: 0.01mm

    Repositioning Accuracy: 0.006mm

    Spindle speed: 200-20000rpm

    spindle taper: HSK-A40A

    Fast moving rate: 56000mm/min

    Cutting feed rate: 1-32000mm/min

    tools magazine: 42

    Maximum machining diameter: 50mm

    Maximum machining length: 130mm

    Maximum machining weight: 2kg

    Dimensions: 1650*2100*2300mm

    Machine Weight: 2600kg
