• Inventory number：84529
• Brand：Okamoto
• Model：ACC-52DX
• Origin：Japan
• Location：China
• Year：2017
• Create Time：2024-08-21

Specifications:

• WorkWorktable size: 550*200mm Chuck size: 500*200*80mm Working Load (including chuck) : 200KGT groove (width X number of slots) : 17X1mm or so feed rate: 0.3~25(m/min) left and right Tool holder rotation for 1 week feed rate: 47(mm) Intermittent feed: 0.2-12(mm) Continuous feed rate: 0.1-1.0(m/min) Non-spark grinding: 0-5 times up and down feed rate: 600mm/min Vertical maximum feed rate: 650(mm) Horizontal feed rate: 230(mm) grinding wheel transfer (50/60HZ) : 3000/3600rpm
