• Inventory number：10796
• Brand：STUDER
• Model：S141
• Origin：Switzerland
• Location：China
• Year：2023
• Create Time：2024-07-23

Specifications:

• Main dimensions

  Swing dia. over the table 400 mm (15.7“)

  Part length including clamping devices max. 700 mm (27.5“)

  Internal grinding length max. 250 mm (9.8“)

  External grinding length max. 150 mm (5.9“)



  Traverse axis X

  Max. travel 425 mm (16.7“)

  Speed 0.001 ~ 20000 mm/min (0.00004 ~ 787 ipm)

  Resolution 0.00001 mm (0.0000004“)



  Longitudinal axix Z

  Max. travel 700 mm (27.5“)

  Speed 0.001 ~ 20000 mm/min (0.00004 ~ 787 ipm)

  Resolution 0.00001 mm (0.0000004“)



  Swiveling Table

  Swiveling range, continuously adjustable –10 to +20 deg.

  Repetition accuracy < 1“

  Swiveling time for 20 deg. < 3s



  Grinding spindle turret

  Spindle set-up Turret

  Max. number of spindles 4

  Swiveling range -50 to +280 deg

  Repetition accuracy < 1“

  Swiveling time for 180 deg. < 4s

  Resolution 0.00005 deg



  Internal Grinding
