Specifications:
Z axis travel 1575mm
X axis travel 360mm
Maximum machining diameter: 660mm
Machining length: 1550mm
Maximum rotating diameter: 875mm
Spindle speed :20 ~ 2000rpm
Spindle power :37kw
Spindle torque: 2270Nm
Tool holder external diameter：32*32mm
Maximum workpiece weight: 1.5t
Tool holder internal diameter:63mm
Machine weight: 13t
24 inches hydraulic chuck
12 positions turret
Fanuc 21i-TB CNC System
Two axes rigid guideway
