Specifications:
Gear tip diameter: 350mm
Maximum workpiece length: 800mm
Maximum machining diameter: 300mm
Worm grinding module: 0.5-8mm
Forming grinding module: 0.5-10mm
Maximum gear width: 320mm
Maximum angle:+/-45 °
Spindle motor: 20kw
Spindle speed: 7500 rpm
Workpiece spindle speed (stepless): 2000 rpm
Grinding wheel diameter: 320mm
Grinding wheel width: 200mm
Total power requirement: 86.4KVA
Machine weight: 16 tons
