• Inventory number：410555
• Brand：Walter
• Model：Helitronic Power Mini
• Origin：Germany
• Location：China
• Year：2006
• Create Time：2024-06-13

Specifications:

• Control system: HMC 600

  X-axis travel: 350mm

  Y-axis travel: 200mm

  Z-axis travel: 470mm

  C axis rotation angle: +/- 200°

  Workpiece spindle: ISO50

  Center height (with/without worktable) : 130/160mm

  Maximum workpiece diameter: 100mm

  Maximum grinding wheel diameter: 150mm

  Spindle power: 9kW

  Load power: approximately  400 volts / 50 Hz / 25 KVA

  Weight:approximately 3600 kg

  Footage w *d * h: 1808 x 2716 x 2393 mm

  Color: RAL 7035/7043 Grey
