• Inventory number：61112
• Brand：Okamoto
• Model：OGM250EXIII
• Origin：Japan
• Location：China
• Year：
• Create Time：2024-05-27

Specifications:

• Distance between centers: 500mm

  Maximum machining  diameter: 200mm

  X-axis travel: 215mm

  Z-axis travel: 762mm

  Grinding wheel size: 355*38*127mm

  Rotation speed: 1614-2247rpm

  Maximum roll speed: 30m/sec

  Worktable rotation angle: 0°/-9°

  Spindle and tailstock through hole: MT3

  Headstock through hole: 18mm

  Rotation speed: 10-500rpm

  Rotation angle: 30°/-90°

  Machine dimension: 2920*2010*1950mm

  Machine weight: 3400kg
