Specifications:
Direction of radius: (0.04+6H/1000) um
Axis direction: (0.04+6X/1000) um
speed: 6rpm
Worktable diameter: 150mm
Maximum load: 25 kg
Centering adjustment range: plus or minus 3mm
Horizontal output adjustment range: plus or minus 1 degree
Maximum measuring diameter: 280mm
Maximum clamping diameter: 440mm
Moving mode: Manually move up and down
travel: 280mm away from the surface of workWorktable
Maximum measurement height: 280mm from the surface of workWorktable
Maximum measuring depth: 100mm (Internal diameter 30mm or more)
Radius direction movement: negative 25-140mm
Measured force: 100mN (plus or minus 30%)
Sampling points: 3600 points/turn
Detection range: + / -1000, + / -100, + / -10um (3 stages)
Measuring range: + -1000, + -500, + -200, + -100, + -50, + -20, + -10, + -5um
Magnification: x 5-200 k times (15 segments)
Can measure the roundness, coaxial degree, concentricity, plane degree, circular degree, straight Angle, off-roundness, parallel degree and so on
