HISION   GRU35E×120
Gantry machining centre
[Product Information:]
  • Inventory number：83430
  • Brand：HISION
  • Model：GRU35E×120
  • Origin：China
  • Location：China
  • Year：2014
  • Create Time：2024-03-07

Specifications:

  • Worktable size :3000*12000mm

    Spindle travel :1500mm

    Worktable load :70t

    T-slot :36*250*48mm

    Gantry width :3800mm

    Three-axis travel :12500*4600*1000mm

    W-axis travel:1250mm

    Distance from spindle end face to worktable:2185mm

    Main motor power :30/37kw

    Spindle speed :10-3500rpm

    Square ram :450*450mm

    Cutting rate :6m/min

    Fast feed rate :10/20/12m/min

    Accuracy:0.006/0.003mm

    Tool holder type:BT50

    Weight :155t

    Dimensions :31000*10000*7300mm
