• Inventory number：83170
• Brand：SUPERTEC
• Model：GM-45CNC
• Origin：Taiwan of China
• Location：China
• Year：2012
• Create Time：2024-01-16

Specifications:

• Internal diameter grinding range: Φ2-Φ400

  Maximum grinding external diameter: Φ450

  Main wheel worktable diameter: 500mm

  Maximum load of main wheel worktable: 50kg

  X*Y*Z axis travel: 500*500*500mm

  X*Y*Z axis servo motor output power: 1.2kw

  Internal grinding spindle motor output power: 2.2kw (2p)

  External diameter grinding wheel spindle motor output power Option: 3.7kw (4P)

  Internal grinding spindle speed: 8000/10000/20000rpm

  External diameter grinding wheel size optional: Φ405*Φ50*Φ127

  Internal grinding wheel size: Φ38*Φ38*Φ8.2
