• Inventory number：91061
• Brand：Tsugami
• Model：G300S-500
• Origin：Japan
• Location：China
• Year：2012
• Create Time：2024-01-06

Specifications:

• Rotating diameter: 300mm

  Distance between centers: 500mm

  Grinding wheel external diameter * maximum width: S:405*75mm, A:510*100mm

  Grinding wheel linear speed: 2700m/min

  X/Z axis feed rate: 16/20m/min

  Dimensions: 2825*3740*1800mm

  Grinding wheel spndle motor power: 7.5kw

  Spindle motor: 1.6kw

  Hydraulic tank: 20L

  Coolant tank: 360L

  Machine weight: 5000kg

  Spindle worktable center type: MT.No4

  Tailstock axis travel: 50mm

  Tailstock center type: MT.No4
