• Inventory number：60150
• Brand：Nagase
• Model：SGC-156
• Origin：Japan
• Location：China
• Year：
• Create Time：2023-12-28

Specifications:

• CNC System :NAGASE

  X*Y*Z axis travel: 1500*600*600mm

  Grinding wheel size (external diameter * width * Internal diameter) : 510*50*127

  Sand wheel shaft :7.5

  Distance from worktable  to spindle center :800mm

  Travel (horizontal, vertical):1800*660

  Minimum feed :0.001

  Spindle drive mode: mechanical direct connection

  Worktable size: 1500*600mm

  Each axis drive mode: YZ shaft: screw drive   X axis: hydraulic pressure drive

  Chip removal mode: tape filtering

  Lead rail :X axis: open static pressure   YZ axis: the linear guideway with a glass scale

  Dimensions :6000*4000*3000mm
