• Inventory number：90952
• Brand：Supertec
• Model：CM-45CNC
• Origin：Taiwan of China
• Location：China
• Year：2013
• Create Time：2023-12-21

Specifications:

• Grinding internal diameter range: 2-400mm

  Maximum grinding external diameter: 450mm

  Rotary diameter on main grinding wheel worktable: 500mm

  Maximum load of main grindind wheel worktable: 50kg

  X*Y*Z axis travel: 500*500*500mm

  X*Y*Z axis servo motor output power: 1.2kw

  Internal grinding spindle motor output power: 2.2kw (2p)

  External diameter grinding wheel spindle motor output power: 3.7kw (4P)

  Internal grinding spindle speed: 8000/10000/20000rpm

  External diameter grinding wheel size : 405*50*127mm

  Internal grinding wheel size: 38*38*8.2mm
