• Inventory number：82973
• Brand：Mazak
• Model：NEXUS 5000-II
• Origin：Japan
• Location：China
• Year：2014
• Create Time：2023-12-20

Specifications:

• Workpiece size :800*1000mm

  Three-axis travel :730*730*740mm

  Distance from spindle nose to tray center :70-810mm

  Distance from spindle center to tray :100-830mm

  Tray worktable surface size :500*500mm

  Pallet load :700kg

  Spindle speed :18000rpm

  Internal diameter of spindle bearing :70mm

  Feed rate :60000mm/min

  Cutting feed rate :1-60000mm/min

  Spindle motor :30/22kw

  Dimensions :2900*2330*5550mm

  Weight :11000kg

  Spindle type: HSK63

  Tool magazine :60

  With center flushing
