Specifications:
CNC System: Heidenhan TNC530
XYZ axis travel: 750*600*560mm)
B axis travel: -10 +110 C axis travel, 3 60 degrees
Distance from spindle to workWorktable surface: 500mm
Spindle resolution: 18000mm
WorkWorktable size: D750
Worktable load: 600KG
Switchboard turning radius: 325mm
Five-axis machine radius: 325mm
Fast moving rate: 90m/min
Tool holder model /HSK63
Number of armor/form: 30 / tray type
Chip discharge method: spiral chip discharge
Drive mode per shaft: linear motor
Guide way: Linear guideway
Spindle transmission mode: electric spindle
Gantry Width: 800mm
Machine tool structure: - a rotating Worktable with swinging head
Overall Footage 3800mmx3000mmx2500mm
Accessories: full axis glass scale laser cutter aligner
Working hours: Power 26,000, use 18,000
