• Inventory number：50415
• Brand：Okuma
• Model：MA-600HB
• Origin：Japan
• Location：China
• Year：2016
• Create Time：2023-11-30

Specifications:

• Spindle speed: 12000rpm

  Spindle: HSK-100

  Full close loop glass scale

  B axis: 1/1000 deg

  Three-axis travel: 1000x900x1000mm

  Height from worktable surface to spindle end face: 50~950mm

  Distance from spindle nose to switching worktable center: 70~1070mm

  Rotary worktable size: 600x600mm

  Worktable load: 1200kg

  Maximum workpiece size: 1000x1000mm

  Spindle diameter: 100mm

  Fast feed rate: 60m/min

  Cutting feed rate: 1~60000mm/min

  Maximum tool length: 450mm

  Maximum tool weight: 25kg

  Machine footage: 3380mmx6495mm

  Net weight: 26000kg

  Positioning accuracy: ±0.004mm

  Repositioning accuracy: ±0.0015mm
