• Inventory number：50247
• Brand：JAINNHER
• Model：JHC-18
• Origin：Taiwan
• Location：China
• Year：2019
• Create Time：2023-10-21

Specifications:

• Standard worktable workpiece diameter: 1~50 mm

  Special worktable workpiece diameter: 40~100mm

  Grinding wheel size :455X305X229mm

  Adjusting wheel size: 255 x305x111mm

  Grinding wheel speed: 1500 RPM

  Adjusting wheel feed handle control box: 3.5mm per revolution, 0.05mm per scale

  Adjusting wheel fine adjustment handle control box: 0.1mm per revolution, 0.001 mm per scale

  Worktable feed handle control box: 9mm per revolution, 0.05mm per scale

  Worktable fine adjustment handle control box: 0.2mm per revolution，0.001mm per scale

  Dressing feed handle control box: 2mm per revolution, 0.01mm per scale

  Adjusting wheel tilting angle: 5°~-3°

  Adjusting wheel rotation angle: ±5°
