• Inventory number：82503
• Brand：CO MING
• Model：KMC-1100VL-P
• Origin：Taiwan of China
• Location：China
• Year：2017
• Create Time：2023-10-20

Specifications:

• X*Y*Z axis travel: 1100*550*610mm

  X*Y*Z axis fast feed rate: 18000*18000*15000mm/min

  Distance from spindle nose to worktable: 100-710mm

  Worktable size: 1300*610mm

  Maximum load: 1200kg

  Spindle speed: 15000rpm

  Tool holder type: BT40

  Maximum tool diameter: 90mm

  Maximum tool length: 250mm

  Maximum tool weight: 20kg

  Dimensions(length * width * height) : 3745*3819*3119mm
